ECO Underfloor Heating Kit 70 SQM with Automation

Name: ECO Underfloor Heating Kit 70 SQM with Automation
Rating: 5 (1 reviews)

Description:

The underfloor heating system represents a comfortable and healthy alternative to classic heating systems, which generates thermal comfort close to ideal, as well as substantial energy savings. Forget thick socks or cold feet; you can safely and comfortably play on the floor. Your usable space will increase, and you will have the freedom to decorate your home as you see fit, and these are just a few of the advantages of underfloor heating.
The entire floor of the room transforms into a radiator that uniformly heats the air in the room, starting from the lower level, thus eliminating the feeling of discomfort caused by a cold floor. In the case of an underfloor heating system, we have small temperature variations vertically in the room, with heat being available where needed. The system uses the heating agent
at much lower temperatures than classic systems, which
generates major reductions in energy costs.

COMFORTABLE
In such a system, the entire floor of the room transforms
into a radiator that uniformly heats the air in the room starting from
the lower level, thus eliminating the sensation of discomfort caused
by a cold floor. In the case of the underfloor heating system,
we have small temperature variations on the vertical of the room,
with heat being available where it is needed.
HEALTHY
Due to small temperature variations, underfloor heating
produces low air movement in the room and thus less
suspended dust and a low risk of allergies. Floors in wet
areas – bathroom, kitchen – will dry faster, reducing the risk of
fungi and mold. It does not dry the air in the room.
ECONOMICAL
Compared to classic systems, it operates at low temperatures of the
heating agent, generating substantial savings of up to 30% on
the heating bill. Working at low temperatures (between 35°C – 45°C),
the system works well with installations that use alternative
energy sources: heat pumps, solar panels, etc. The underfloor
heating system, correctly sized, can cover the entire
thermal requirement with reduced energy costs.
SIMPLE
Correctly designed, underfloor heating systems can be
installed practically under any type of floor finish – stoneware, ceramic
tiles, parquet, etc. It does not occupy room space, offering you complete
freedom in interior design and furniture installation. The system
can be installed throughout the entire dwelling or only in certain rooms.
RELIABLE
It is safe and does not require maintenance operations. The estimated lifespan
of the PEX/PE-RT pipe is comparable to that of the building, approximately
50 years.

ADVANTAGES
PE-RT pipe warranty 20 years
System components warranty 10 years
Automation warranty 2 years
Free sizing
Can be fully automated
Compatible with any finish
Lifespan of over 50 years

Valrom Industrie provides one of the most efficient and
easiest-to-install underfloor heating kits, the perfect solution
to heat any home with an area of 70 m².
The kits include the components required to install a water-based
underfloor heating system. Floor thermal insulation is carried out before
installing the system. From a technical standpoint, the kit contents do not
replace a design project. They were established according to the estimated
material requirement for underfloor heating of each
area.
The kits do NOT include the thermal insulation panels (stud panels);
the choice of panel type belongs to the contractor.
The material requirement in the kits was determined considering a
10 cm pipe laying spacing; for the thermal calculation it was
considered the 20 kg/m³ stud panel 57/35 mm 1000 x 500 mm (code:
64192050126).
At the customer’s request, Valrom Industrie provides free
sizing for underfloor heating systems using the
ExpertKIT program.

SKU: PEX002011016071 Category: UNDERFLOOR HEATING PIPES
