EXPANSION CONNECTOR TRIPLUS LONG D. 75
Used in indoor drainage systems for:
• gravity-fed discharge of domestic wastewater, at low or high temperatures;
• ventilation of drainage systems;
• rainwater collection systems within the building structure.
Reference standard: EN 1451-1.
Material:
• Triple-layer pipes:
o inner/outer layer: polypropylene
o intermediate layer: mineral-reinforced polypropylene.
• Fittings: single-layer, mineral-reinforced polypropylene.
The size range includes diameters from 32 mm to 250 mm.
Joining method: socket with gasket.
Acoustic performance: 12 dB(A) for a flow rate of 4 l/s and <10 dB(A) for a flow rate of 2 l/s. The sound-absorbing properties are certified following measurements performed in the laboratories of the Fraunhofer Institute in Germany, in accordance with EN 14366. The use of sound-absorbing clamps is recommended.
Fire classification: D-s2, d0, according to EN 13501-1.
To reduce the noise level of indoor drainage systems, the following are recommended:
• Selecting a pipe and fitting system with good sound-absorbing properties;
• Ensuring correct system design;
• Correct installation of the system using appropriate products.
• gravity-fed discharge of domestic wastewater, at low or high temperatures;
• ventilation of drainage systems;
• rainwater collection systems within the building structure.
Reference standard: EN 1451-1.
Material:
• Triple-layer pipes:
o inner/outer layer: polypropylene
o intermediate layer: mineral-reinforced polypropylene.
• Fittings: single-layer, mineral-reinforced polypropylene.
The size range includes diameters from 32 mm to 250 mm.
Joining method: socket with gasket.
Acoustic performance: 12 dB(A) for a flow rate of 4 l/s and <10 dB(A) for a flow rate of 2 l/s. The sound-absorbing properties are certified following measurements performed in the laboratories of the Fraunhofer Institute in Germany, in accordance with EN 14366. The use of sound-absorbing clamps is recommended.
Fire classification: D-s2, d0, according to EN 13501-1.
To reduce the noise level of indoor drainage systems, the following are recommended:
• Selecting a pipe and fitting system with good sound-absorbing properties;
• Ensuring correct system design;
• Correct installation of the system using appropriate products.
| UM colete | BOX |
|---|---|
| Tip articol | CONNECTOR |
| Cod CPV | CPV 44134000-8 |
| Cantitate colet | 20 |
| Diametru | 75 |
| Cod vamal | 39174000 |
| Subclasa | TRIPLUS VALSIR TRIPLUS FITTINGS |
