Used in interior drainage systems for the evacuation of domestic wastewater in gravity flow (where the tightness test is performed at max. 0.5 bar), where sound dampening from water discharge is desired.
Reference standard: EN 1451.
Black color, mass-colored, single-layer, made of PP with mineral additives.
Size range includes diameters from 32 mm to 160 mm.
Socket and gasket joining system, no special tools, adhesives or solvents required.
Acoustic performance is 16 dB for a flow rate of 2 l/s. Sound-absorbing properties are certified following measurements performed in the laboratories of the Fraunhofer Institute in Germany, according to EN 14366. The use of sound-absorbing clamps is recommended.
Fire behavior classification, in accordance with DIN 4102-1, is class B1. For ceiling penetrations, we recommend using fire-stop collars as a protective measure against flame propagation.
To reduce noise levels in interior drainage systems, we recommend:
• Selecting a pipe and fitting system with good sound-absorbing properties;
• Proper design of the installations;
• Correct installation of the system using appropriate products.

Material	PP
Tip articol	TOC
UM colete	PIECE
Cod CPV	CPV 44167300-1
Cantitate colet	1
Diametru	40
Diametru(mm)
Unghi	45 Grade
Cod vamal	39174000
Subclasa	FITTINGS PP SOUND ABSORBING SEWAGE PIPES
