Used for:
• Cold/hot water supply plumbing systems
• High-temperature radiator heating systems
Through sliding sleeves, a non-detachable connection is made between the brass fitting and PE-X/PE-RT class A series 3.2 pipes, with the following diameter x wall thickness characteristics: 16x2.2, 20x2.8, 25x3.5, 32x4.4.
Reference Standard: EN ISO 15875-3 : 2003. Plastics piping systems for hot and cold water installations. Crosslinked polyethylene (PE-X). Part 3: Fittings.
Material: CW617N brass (with Pb2.2% and Ni 0.1% according to EU regulations for use in potable water).
The thread is tapered BSP with thread sealing according to "SR EN 10226-1:2004 Pipe threads where pressure-tight joints are made on the threads. Part 1: Taper external threads and parallel internal threads. Dimensions, tolerances and designation"
Pressure rating: maximum 10 bar.
Dedicated installation tools are required to connect the fittings and piping.

Filet	FE
DZP	FROM
Ambalare	CARDBOARD BOX / PLASTIC BAG
Tip articol	RACORD
UM colete	SMALL BAG
Cod CPV	CPV 44167300-1
Cantitate colet	6
Diametru	20×½"
Durata estimata de viata	50 Years
Perioada garantie	60 Months
Cod vamal	39174000
Subclasa	PPSU fittings for radiator heating
