VALStock CYLINDRICAL VERTICAL DISPENSER FOR LIQUIDS V=600 L
Food liquid dispenser – scope of use and specifications
Important: the metal stand:
is NOT included in the package. It can be purchased separately using code 49150000004 VALStock METAL STAND FOR SUPPORTING CYLINDRICAL VERTICAL DISPENSER V=600 L.
Scope of use:
-
The dispenser is intended for storing drinking water and food liquids, at atmospheric pressure and temperatures between 5–65 °C.
-
It can be used in the food industry, agriculture, or other similar applications (e.g., preparation of liquid compounds).
-
It is designed for gravity discharge of stored liquids and for easy cleaning of the inside of the tank.
Use restrictions:
-
It CANNOT be used for liquids at pressures below or above atmospheric pressure (1 atm).
-
It is NOT suitable for fuels, petroleum products, or chemically aggressive substances.
Design features:
-
Equipped with a sealed lid, secured with a gasket.
-
The lower part is fitted with a connection kit: nipple + 1” nut, rubber gaskets, and plug.
-
Manufactured using rotomolding technology, from polyethylene and/or ethylene copolymers, in a monobloc, white, single-layer structure..
Dimensions:
-
PE tank height: 1480 mm
-
Height with stand: 1850 mm
-
Diameter: 775 mm
-
PP lid: ø 300 mm
Food liquid dispenser – professional use
The dispenser is intended for storing drinking water and other food liquids, at atmospheric pressure, within the 5–65 °C temperature range. It can be used in the food industry, agriculture, for preparing compounds, etc.
The dispenser is designed to allow gravity discharge of stored liquids and easy cleaning of the tank.
Technical features:
-
Not intended for use at pressures other than atmospheric (1 atm).
-
Not compatible with fuels, petroleum products, or chemically aggressive substances.
-
The dispenser is equipped with a lid and a gasket-based sealing system, as well as a bottom kit consisting of a nipple, 1" nut, rubber gaskets, and plug.
-
Manufactured using rotomolding technology, from polyethylene and/or ethylene copolymers, in a single-layer structure, opaque white color.
-
The surface is smooth, with no visible defects (no air bubbles, cracks, chips, or other imperfections that may affect functionality).
-
Edges are well defined, and manufacturing flash is removed.
Dimensions:
-
PE tank height: 1480 mm
-
Dispenser height mounted on stand: 1850 mm
-
Diameter: 775 mm
-
PP lid: Ø 300 mm
| UM colete | PIECE |
|---|---|
| Ambalare | NEAMBALAT |
| Tip articol | DISPENSER |
| Cod CPV | CPV 44611500-1 |
| Cantitate colet | 1 |
| Perioada garantie | 24 Months |
| Durata estimata de viata | 25 Years |
| Cod vamal | 39251000 |
| Subclasa | PLASTIC WATER TANKS |
